EBC 629 Carbon Graphite Rear Brake Shoes – Suzuki LT-4WD / LT-F250 QuadRunner
$27.95
EBC plain 165 x 28 mm rear drum brake shoe set for Suzuki LT-4WD and LT-F250 QuadRunner ATV variants. Organic carbon graphite, asbestos-free lining.
Selected fitment: Suzuki LT-4WD QuadRunner 250 4WD, 1987-1996: rear. Suzuki LT-F250 QuadRunner 250, 1988-2001: rear. New old stock; one packaged set.
1 in stock
EBC 629 Carbon Graphite Rear Brake Shoes – Suzuki LT-4WD / LT-F250 QuadRunner
Condition: New old stock in older packaging with shelf wear; inspect box contents and springs before installation.
Brand: EBC
Manufacturer part number: 629
Part type: Drum brake shoe set
Style: Plain / standard
Friction lining: Organic carbon graphite, asbestos-free bonded lining
Shoe diameter x lining width: 165 x 28 mm
Placement: Rear
Sale unit: One manufacturer-packaged set; stock quantity counts sets, not individual shoes.
EBC describes its replacement shoes as asbestos-free bonded linings, radius-ground and edge-trimmed with chamfered lining ends. The Plain / standard version is the plain replacement shoe; the separate G suffix denotes grooved shoes. Original-equipment style springs are part of EBC’s current product specification; confirm the contents of this older boxed set before installation.
Applications and brake location
- Suzuki LT-4WD QuadRunner 250 4WD, 1987-1996: rear.
- Suzuki LT-F250 QuadRunner 250, 1988-2001: rear.
- Suzuki LT-F250F QuadRunner 250 4WD, 1999-2002: rear.
- Suzuki LT-F4WD QuadRunner, 1997-1998: rear.
Part references: EBC shoe pattern 629, 165 x 28 mm. Check exact LT / LT-F variant and rear drum.
Vehicle model, model year, trim and brake location matter. Compare the old shoe outline, drum size and vehicle parts diagram before purchase. One shoe pair services one drum; a two-front-drum ATV may require two sets. Packaging age and minor label wear do not change the stated part number.
| Weight | 1.1875 lbs |
|---|---|
| Dimensions | 8 × 6 × 4 in |
| Condition |
New Old Stock |
| Manufacturer Part Number |
629 |
| Placement on Vehicle |
Rear |
| Part Type |
Drum Brake Shoe Set |
| Shoe Diameter x Width |
165 x 28 mm |
